Supco Bullet Piercing Valve

BPV31

SUPCO’S “Bullet Piercing Valve” utilises the same type of gasket found under the head plate of most air conditioning compressors. When
installed, the gasket actually compresses the copper tubing .020″ creating a “Permanent”, leak-proof seal that will withstand any pressure and temperature for the life of the unit.

Application:-

• Install on the high side as a “Permanent” valve on the job
• The Bullet Piercing Valve will not leak
• Install on round suction lines or uneven tubing

​Product Details:-

• Hex key wrench included – No additional tools required
• Non-positional mounting – No adaptor valve required
• Precision piercing needle is engineered for concentricity and hardness to insure perfect seating every time
• Patented valve gasket application provides 50 times more sealing area than competitive “O” ring types
• A sealing force of over 180 inch lbs., torque tested with 500 lbs., pressure tested at 250°F
• Requires only a 2″ clearance area for installation and operation
• Provided with a corrosion resistant plated and lacquered finish
• 450 PSI Max (31 Bar)

​For 1/4″, 5/16″, 3/8″ tubing.
